| Measuring Range* | 10 - 800 Hz |
| Indicator error | ±1 Hz |
| Total error | < 5 % |
| Sensing Distance*** | 0.200" - 1.6" (5 - 40 mm), typically (2.5"/60 mm max, depending upon ambient light & surface of belt to be measured) |
| Casing | ABS Plastic |
| Display | 2 line LCD, 16 character per line |
| Input Range | free span length: up to 9.990 m belt mass: up to 9.999 kg/m |
| Belt Density | Belt Density (d = kg/m or lb/ft) |
| Belt Span | Min, approx. 10 cm (4 inch) Max, no maximum (as long as belt will oscillate) |
| Warranty | 1 Year |
| Light Source | Red LED |
| Light Size | at 50mm - 6mm Square at 150mm - 15mm Square |
| Power Supply | 9V battery |
| Metric Units | MASS must be entered in kg/meter SPAN in "meters" |
| English Units | MASS must be entered in lbs/ft SPAN in "inches" |
| Operation Video | https://www.youtube.com/watch?v=-l4-uG0JIAc&feature=youtu.be |
| Country of Origin | Germany |
**Static tension (T) accuracy depends on the precision of entered values for free belt span (L), density (d) and natural frequency (f) of the vibrating free belt span, that has been plucked or struck, as noted in the relationship: T = 4dL2f2. Note that highest accuracy is achieved in the frequency mode where readings are accurate to <1%, ± 1 Hz.
***Sensing distance can be extended when ambient light level is low also by adding a piece of reflective tape in the "target area" of the belt.
