DESCRIPTION:

DC power supply with three output channels (+30 V / 3 A, +30 V / 3 A, +5 V / 3 A, DC, max 195 W) EU Cable

Ripples and Noise (20Hz-20MHz): Normal Mode Voltage：<350μVrms/3mVpp; Normal Mode Current：<2mArmss

Std. Programming resolution: 10mV/10mV/10mV.

Voltage Resolution: 1mV/1mV/1Mv (option)

LAN, RS232 and Digital IO Ports (option)

Online Monitoring & Analysis Function (option)

Standard Timing output; Built-in V,A,W measurements and waveform display

3.5 inch TFT display, easy for operation

Specifications	Rigol DP832
Outputs	3
Output 1	0 to +30 V/DC with max. 3 A
Output 2	0 to +30 V/DC with max. 3 A
Output 3	0 to +5 V/DC with max. 3 A
Ground Sharing	Output 1 sole GND, Output 2 + Output 3 shared GND
Output Power (max.)	195 W
Overtemperature shut down	55 °C
Working Temperature	0 °C to 40 °C
Cooling Method	Fan cooling

Output Voltage	Output 1	Output 2	Output 3
Output Voltage	0 to +30 V/DC	0 to +30 V/DC	0 to +5 V/DC
Accuracy	±0.05% + 10 mV	±0.05% + 10 mV	±0.05% + 10 mV
Resolution	10 mV (1 mV with High-Resolution Option)	10 mV (1 mV with High-Resolution Option)	10 mV (1 mV with High-Resolution Option)
Overvoltage Protection	10 mV to 33 V	10 mV to 33 V	10 mV to 5.5 V
Load Regulation	< 0.01% + 2 mV
Line Regulation	< 0.01% + 2 mV
Ripple and Noise	< 350 μV rms / 2 mVpp

Output Current	Output 1	Output 2	Output 3
Output Current (max.)	3 A	3 A	3 A
Accuracy	±0.15% + 5 mA	±0.15% + 5 mA	±0.15% + 5 mA
Resolution	10 mA (1 mA with High-Resolution Option)	10 mA (1 mA with High-Resolution Option)	10 mA (1 mA with High-Resolution Option)
Overcurrent Protection	1 mA to 3.3 A	1 mA to 3.3 A	1 mA to 3.3 A
Load Regulation	< 0.01% + 250 μA
Line Regulation	< 0.01% + 250 μA
Ripple and Noise	< 2 mA rms

Programmable power supply	Rigol DP832
Display	8.9 cm (3.5") WVGA-Monochrome-LCD
Resolution	320 × 240 Pixel
Additional Interfaces	USB host for connecting USB sticks to store settings USB device for connection to a PC LAN for use on a network (LXI) (option) RS232 (option) GPIB (IEE-488, General Purpose Interface Bus, only with optional adapter) Separate ground connection Digital IO Ports (option)
Dimensions (W × H × D)	23.9 cm × 15.7 cm × 41.8 cm (9.41" × 6.18" × 16.46")
Weight	9.0 kg (19.84 lbs)
Supported operating systems	XP, Vista, Win 7 (32Bit + 64Bit), Win 8 (32Bit + 64Bit), Win 10 (32Bit + 64Bit)
Input	230 V/AC, 115 V/AC or 100 V/AC (adjustable)
Tracking function	The two 30 V outputs can be coupled. When the tracking function is activated, you only need to change one output and the other 30 V output is automatically set to the same value (with the corresponding reverse polarity).
