DSO-TC4 FNIRSI

Name: DSO-TC4 FNIRSI
Brand: FNIRSI
Price: 18000.00 PKR
Availability: InStock

New

DSO-TC4 FNIRSI

Stock: In Stock
Model: 3in1 Portable Digital Oscilloscope

FNIRSI

Based on 0 reviews. - Write a review

18,000

+ 500 Shipping charges

Qty

Add to Cart

Ask for price

Add to Wish List Compare this Product

Description

The FNIRDSI DSO-TC4 is a multifunctional transistor oscilloscope that is both comprehensive and practical. It is designed for use in maintenance and R&D applications, integrating an oscilloscope, transistor tester, and signal generator into a single device.

Features

Equipped with a 2.8-inch TFT color screen for a clear and intuitive display
Built-in high-capacity rechargeable lithium battery (1500 mAh) with a standby time of up to 4 hours
Compact and lightweight, ideal for mobile use

Specifications

Oscilloscope
Analog Bandwidth	10 MHz
Real-Time Sampling Rate	48 MSa/s
Input Impedance	1 MΩ
Coupling Mode	AC/DC
Test Voltage Range	1:1 Probe: 80 Vpp (+40 V)
Test Voltage Range	10:1 Probe: 800 Vpp (+400 V)
Vertical Sensitivity	10 mV/div~10 V/div (X1 range)
Vertical Displacement	Adjustable with indication
Time Base Range	50ns~20s
Trigger Mode	Auto/Normal/Single
Trigger Type	Rising edge, Falling edge
Trigger Level	Adjustable with indication
Waveform Freeze	Yes (HOLD function)
Automatic Measurement	Max, Min, Avg, RMS, Vpp, Frequency, Cycle, Duty Cycle
Component Tester
Transistor	Amplification factor "hfe"; Base-Emitter voltage "Ube", Ic/Ie, Collector-Emitter reverse leakage current "Iceo", Ices, Forward voltage drop of protection diode "Uf"
Diode	Forward voltage drop <5 V (Forward voltage drop, Junction capacitance, Reverse leakage current)
Zener Diode	0.01~32 V
Zener Diode	Reverse Breakdown Voltage (K-A-A Test Area)
Field-Effect Transistor (FET)	JFET: Gate capacitance "Cg", Drain current Id under "Vgs", Forward voltage drop of protection diode "Uf"
	IGBT: Drain current Id under Vgs, Forward voltage drop of protection diode Uf
	MIOSTET: Threshold voltage "Vt", Gate capacitance "Cg", Drain-Source resistance "Rds", Forward voltage drop of protection diode "Uf"
Unidirectional SCR	Trigger voltage <5V, Gate level (Gate voltage)
Bidirectional SCR	Trigger current <6mA (Gate voltage)
Capacitor	25pF~100mF, Capacitance value, Loss factor "Vloss"
Resistor	0.01Ω~50MΩ
Inductor	10μH~1000μH, DC resistance
DS18B20	Temperature sensor, Pins: GND, DQ, VDD
DHT11	Temperature and humidity sensor, Pins: VDD, DATA, GND
Signal Generator
Output Waveform	Supports 13 waveform outputs
Waveform Frequency	0-50 KHz
Square Wave Duty Cycle	0-100%
Waveform Amplitude	0.1-3.0 V
General
Display	2.8-inch TFT color screen
Backlight	Brightness adjustable
Power Supply	USB-C (5 V/1 A）
Battery	3.7 V/1500 mAh
Languages	English, German, Spanish, Portuguese, Russian, Chinese, Japanese, Korean
Dimensions	90 x 142 x 27.5 mm
Weight	186 g
