GM318B BENETECH

INTROSUCTION:

THIS THERMOMETER IS USED FOR MEASURING THE TEMPERATURE OF THE OBJECT'S SURFACE, WHICH IS APPLICABLE FOR VARIOUS HOT, HAZARDOUS OR HARD TO REACH OBJECTS WITHOUT CONTACT SAFELY AND QUICKLY.

THE PRODUCT CONSIST OF OPTICS, TEMPERATURE SENSOR SIGNAL AMPLIFIER PROCESSING CIRCUIT & LCD DISPLAY. THE OPTICS COLLECTED THE INFRARED ENERGY EMITTED BY OBJECT AND FOCUS ONTO THE SENSOR. THEN THE SENSOR TRANSLATES THE ENERGY INTO AN ELECTRICITY SIGNAL. THIS SIGNAL WILL BE TURNED OUT TO BE DIGITAL SHOWN ON THE LCD AFTHER THE SIGNAL AMPLIFIER AND PROCESSING CIRCUIT.

SPECIFICATION:

TEMPERATURE RANGE: -50 ~ 590 C (-58~1094 F)

ACCURACY: < 0 C (32 F) : + 3 C (+ 5 F)
                     < 0 C (32 F) : + 2% OR + 2 C C (+ 5 F), WHICHEVER IS GREATER

REPEATABILITY: 1% OF READING OR 1 C

RESPONCE TIME: 500 mSEC, 95% RESPONCE

SPECTRAL RESPONSE: 5 ~ 14um

EMISSIVITY 0.95 PRESET, ADJUSTABLE FROM
                                            0.10 TO 1.00

OPERATING TEMPERATURE: 0 ~ 40 C (32 ~ 104F)

OPERATING HUMIDITY: 10 ~ 90 % RH NON-CONDENSING

STORAGE TEMPERATURE: -20~60 C (-4 ~ 140F)

POWER 1.5 V AAA *2 BATTERY

BATTERY LIFE 12H (LASER OFF)

DISTANCE TO SPOT SIZE 12:1
