KEW2062BT KYORITSU

Pre-Order

KEW2062BT KYORITSU

Stock: Pre-Order
Model: CLAMP POWER METER

Description

A tear drop shape jaw with the conductor size 55 mm: Convenient to use at a small-sized office and factory

Current up to 1000A rms
Voltage up to 1000V rms
Harmonics up to 30th
KEW 2062 and KEW 2062BT have a tear drop shape jaw, and the size is convenient to use at a small-sized office and factory (Conductor size 55mm)

Specification

Wiring connections		1P2W, 1P3W, 3P3W, 3P4W
Measurements and parameters		Voltage, Current, Frequency, Active power, Reactive power, Apparent power, Power factor(cosθ), Phase angle, Harmonics(THD-R/THD-F), Phase rotation
ACV

	Range	1000V
	Accuracy	±0.7%rdg±3dgt (40.0 to 70.0Hz) ±0.3%rdg±5dgt (70.1Hz to 1KHz)
	Crest factor	1.7 or less
ACA

	Range	40.00/400.0/1000A (3 range auto)
	Accuracy	±1.0％rdg±3dgt (40.0 to 70.0Hz) ±2.0％rdg±5dgt (70.1Hz to 1kHz)
	Crest factor	3 or less on 40.00A/400.0A range, 3 or less 1500A peak on 1000A range
Frequency

	Display Range	40.0 to 999.9Hz
	Accuracy	±0.3％rdg±3dgt
Active power

	Range	40.00/400.0/1000kW
	Accuracy	±1.7%rdg±5dgt (PF1, sine wave, 45 to 65Hz)
Apparent power

	Range	40.00/400.0/1000kVA
	Accuracy	±1dgt against each calculated value Sum: add errors of each channel, 3P3W: ±2dgt, 3P4W:±3dgt
Reactive power

	Range	40.00/400.0/1000kVar
	Accuracy	±1dgt against each calculated value Sum: add errors of each channel, 3P3W: ±2dgt, 3P4W:±3dgt
Power factor

	Display Range	-1.000 to 0.000 to +1.000
	Accuracy	±1dgt against each calculated value Sum: add errors of each channel, 3P3W: ±2dgt, 3P4W:±3dgt
Phase angle (1P2W only)

	Display Range	-180.0 to 0.0 to +179.9
	Accuracy	Within ±3.0°
Harmonics RMS(Content rate)

	Analysis order	1st to 30th order
	Accuracy	±5.0％rdg ± 10dgt (1 to 10th) ±10％rdg ± 10dgt (11 to 20th) ±20％rdg ± 10dgt (21 to 30th)
Total harmonics THD-R/THD-F

	Display Range	0.0% to 100.0%
	Accuracy	±1dgt against the calculated results of each measured value
Phase rotation		ACV 80 to 1100V (45 to 65Hz)
Other functions		MAX/MIN/AVG/PEAK, Data hold, Bluetooth^®, Backlight, Auto power off
General

	Communication interface	Bluetooth^® 5.0
	Power source	LR6 (AA) (1.5V) ×2
	Continuous measuring time	Approx. 58 hours
	Conductor size	φ55 mm max.
	Dimension / Weight	247(L) × 105(W) × 50(D) mm / Approx. 490g (including batteries)
	Applicable standards	IEC 61010-1, IEC 61010-2-032, IEC 61326-1,2-2 ClassB CAT Ⅳ 300V / CAT Ⅲ 600V / CAT Ⅱ 1000V Pollution degree 2
