KEW2204R KYORITSU

Name: KEW2204R KYORITSU
Brand: KYORITSU
Availability: OutOfStock

Pre-Order

KEW2204R KYORITSU

Qty

Flexible and light weight clamp sensor

AC A
	Range	4.000/40.00/400A
	Accuracy	±3%rdg±5dgt [45 to 500Hz] (At the center of the circle formed by the flexible sensor)
	Accuracy
	Crest factor (CF)	Full scale CF<1.6, half scale<3.2 Effective input crest values are √2 times of the max values of each range.
	Crest factor (CF)
Conductor size		φ70mm max.
Influence of Conductor position		Additional ±2% (max.) depending on the distance from the center position
Influence of Conductor position
Overload protection		500A AC for 10 seconds
Applicable standards		IEC 61010-1, IEC 61010-2-032 CAT Ⅳ 600V / CAT Ⅲ 1000V Pollution degree 2 IEC 61326-1(EMC) , IEC 60529 IP40 , EN50581(RoHS)


Operating temperature and humidity range		0 to +50℃,relative humidity 80% or less(no condensation)
Operating temperature and humidity range		0 to +50℃,relative humidity 80% or less(no condensation)
Storage temperature and humidity range		-10 to +60℃,relative humidity 70% or less(no condensation)
Storage temperature and humidity range		-10 to +60℃,relative humidity 70% or less(no condensation)
Power source		R03 / LR03(AAA)(1.5V)×2 ※Continuous measuring time：Approx.120hours (Auto power off：Approx.15 minutes)


Dimension		120(L)×70(W)×26(D)：Display unit φ5.5mm approx.：Cable diameter 1.8m : Cable length


Weight		Approx. 200g (including batteries)
