KEW8122 KYORITSU
Pre-Order
KEW8122 KYORITSU
- Stock: Pre-Order
- Model: LOAD CURRENT CLAMP SENSOR
Specification
Conductor size Ø40mm Rated current AC 500A Output voltage AC 500mV/500A (AC 1mV/A) Accuracy ±2.0%rdg±0.3mV (50/60Hz)
±3.0%rdg±0.5mV (40Hz to 1kHz) Cable length Approx. 2m Output connector MINI DIN 6PIN Output impedance Approx. 1.9Ω Applicable standards IEC 61010-1 , IEC 61010-2-032 CAT III 600V pollution degree 2 , IEC 61326 Operating temperature and humidity range 0 to 40°C , relative humidity 85% or less (no condensation) Dimension 128(L) x 81(W) x 36(D) mm Weight Approx.260g
| Conductor size | Ø40mm |
|---|---|
| Rated current | AC 500A |
| Output voltage | AC 500mV/500A (AC 1mV/A) |
| Accuracy | ±2.0%rdg±0.3mV (50/60Hz) ±3.0%rdg±0.5mV (40Hz to 1kHz) |
| Cable length | Approx. 2m |
| Output connector | MINI DIN 6PIN |
| Output impedance | Approx. 1.9Ω |
| Applicable standards | IEC 61010-1 , IEC 61010-2-032 CAT III 600V pollution degree 2 , IEC 61326 |
| Operating temperature and humidity range | 0 to 40°C , relative humidity 85% or less (no condensation) |
| Dimension | 128(L) x 81(W) x 36(D) mm |
| Weight | Approx.260g |
