KEW8124 KYORITSU
Pre-Order
KEW8124 KYORITSU
- Stock: Pre-Order
- Model: LOAD CURRENT CLAMP SENSOR
Specification
| Conductor size | Ø68mm |
|---|---|
| Rated current | AC 1000A |
| Output voltage | AC 500mV/1000A (AC 0.5mV/A) |
| Accuracy | ±0.5%rdg±0.2mV (50/60Hz) ±1.5%rdg±0.4mV (40Hz to 1kHz) |
| Phase shift | within ±1.0º (45 to 65Hz) |
| Cable length | Approx. 3m |
| Output connector | MINI DIN 6PIN |
| Output impedance | Approx. 1Ω |
| Applicable standards | IEC 61010-1 , IEC 61010-2-032 CAT III 600V pollution degree 2 , IEC 61326 |
| Operating temperature and humidity range | 0 to 50˚C , relative humidity 85% or less (no condensation) |
| Dimension | 186(L) x 129(W) x 53(D) mm |
| Weight | Approx. 510g |
