KEW8130 KYORITSU

KEW8130 KYORITSU
Pre-Order
KEW8130 KYORITSU
  • Stock: Pre-Order
  • Model: FLEXIBLE CLAMP SENSOR

Ø110mm

  • Can measure AC current up to 1000A
  • Flexible and light weight by the air core coil used at the sensor part
  • Designed to meet the international safety standard IEC 61010-1 CAT IV 300V, CAT III 600V

    Specification

  • Conductor size
  • max.Ø110mm
  • Rated current
  • AC 1000A
  • Output voltage
  • AC 500mV / 1000A (AC 0.5mV/A)
  • Accuracy
  • ±0.8%rdg±0.2mV (45Hz to 65Hz)
    ±1.5%rdg±0.4mV (40Hz to 1kHz)
  • Phase shift
  • within ±2.0° (45Hz to 65Hz)
  • Cable length
  • Approx. 3m
  • Output connector
  • MINI DIN 6PIN
  • Output impedance
  • 100Ω or less
  • Applicable standards
  • IEC 61010-1 , IEC 61010-2-030
    IEC 61010-2-032 CAT IV 300V / CAT III 600V Pollution degree 2
    IEC 61326
  • Operating temperature and humidity range
  • -10 to 50°C , relative humidity 85% or less (no condensation)
