KEW8133 KYORITSU

Name: KEW8133 KYORITSU
Brand: KYORITSU
Availability: OutOfStock

Pre-Order

KEW8133 KYORITSU

Qty

Ø170mm

Can measure AC current up to 3000A
Flexible and light weight by the air core coil used at the sensor part
Designed to meet the international safety standard IEC 61010-1 CAT IV 300V, CAT III 600V

Specification

Conductor size	max.Ø170mm
Rated current	AC 3000A
Output voltage	AC 500mV / 3000A (AC 0.167mV/A)
Accuracy	±1.0%rdg±0.5mV (45Hz to 65Hz) ±1.5%rdg±0.5mV (40Hz to 1kHz)
Phase shift	within ±2.0° (45Hz to 65Hz) within ±3.0° (40Hz to 1kHz)
Cable length	Approx. 3m
Output connector	MINI DIN 6PIN
Output impedance	100Ω or less
Applicable standards	IEC 61010-1 , IEC 61010-2-032 CAT IV 300V / CAT III 600V Pollution degree 2 , IEC 61326
Operating temperature and humidity range	-10 to 50°C , relative humidity 85% or less (no condensation)
Weight	Approx. 200g
