KEW8146 KYORITSU
Pre-Order
KEW8146 KYORITSU
- Stock: Pre-Order
- Model: LEAKAGE & LOAD CURRENT CLAMP SENSOR
Specification
| Conductor size | Ø24mm |
|---|---|
| Rated current | AC 30A |
| Output voltage | AC 1500mV/30A (AC 50mV/A) |
| Accuracy | 0 to 15A ±1.0%rdg±0.1mV (50/60Hz) ±2.0%rdg±0.2mV (40Hz to 1kHz) 15 to 30A ±5.0%rdg (50/60Hz) ±10.0%rdg (45Hz to 1kHz) |
| Cable length | Approx. 2m |
| Output connector | MINI DIN 6PIN |
| Output impedance | Approx. 90Ω |
| Applicable standards | IEC 61010-1 , IEC 61010-2-032 CAT III 300V pollution degree 2 , IEC 61326 |
| Operating temperature and humidity range | 0 to 50°C , relative humidity 85% or less (no condensation) |
| Dimension | 100(L) x 60(W) x 26(D) mm |
| Weight | Approx.150g |
