KEW8178 KYORITSU

Applicable model

5050

Conductor size

Ø68mm

Rated current

10A (rms) AC (14.1Apeak)

Output voltage

500mV AC/10A AC

Accuracy

±1.0%rdg±0.025mV (40 to 70Hz)
±4.0%rdg±0.025mV (30Hz to 5kHz , with inputs of 100mA or more)

Phase shift

within 1.0°
(45 to 70Hz while combining with KEW 5050 , under the input of 10% or more of KEW 5050 leakage current range)

Cable length

Approx. 3m

Output connector

MINI DIN 6PIN

Output impedance

Approx. 60Ω or less

Applicable standards

IEC 61010-1 , IEC 61010-2-032 CAT Ⅲ 300V Pollution degree 2 , IEC 61326-1

Operating temperature and humidity range

-10 to 50°C , relative humidity 85% or less (no condensation)

Dimension

186(L) × 129(W) × 53(D)mm

Weight

Approx. 560g

Accessories

9094 (Carrying case) , Instruction manual
