KEW8601 KYORITSU
- Stock: Pre-Order
- Model: EVSE ADAPTER
Dedicated adapter for EVSE
(Electric Vehicle Supply Equipment)
installation inspections, maintenance and troubleshooting
Compact adapter for complete testing of Mode 3 AC EVSE
- EVSE
tests under various simulations
- Touch
pad for PE voltage check
- CP
signal terminals for CP signal monitoring
*Supporting normal chargers (AC) only, not supporting fast
(DC) chargers
Measurable tests by KEW 8601
| ||
KEW
8601 | KEW
8601 | |
CP
state | ✓ | |
CP
Error | ✓ | |
PE
Error | ✓ | |
Live
LED | ✓ | |
Volts | ー | ✓ |
Insulation | ー | ✓ |
Earth | ー | ✓ |
RCD | ー | ✓ |
Checking
CP signal | ー | ✓ |
Specification
Plug | SAE J1772 / IEC 62196-2 Type 1 |
Rated
voltage | AC 250V Max. |
Rated
Frequency | 50/60Hz |
Operating temperature and
humidity range | 0 to 40ºC, relative humidity 80 % or less (no
condensation) |
Storage temperature and
humidity range | -10 to 50ºC, relative humidity 80 % or less (no
condensation) |
Applicable
standards | IEC 61010-1, IEC 61010-2-030 CAT Ⅱ 250V |
Altitude | 2000m or less |
Cable
length | Approx. 250mm |
Dimension | Unit: 172(L) x 105(W) x 57(D) mm |
