KEW2007R KYORITSU Price In Pakistan

AC A

600.0/1000A (Auto-ranging)

±1.5%rdg±4dgt [45 to 65Hz]

±2.0%rdg±4dgt [40 to 400Hz]

AC V

600.0V

±1.2%rdg±3dgt [45 to 65Hz]

±1.5%rdg±4dgt [40 to 400Hz]

DC V

600.0V

±1.2%rdg±3dgt

Ω

600.0Ω/6.000kΩ (Auto-ranging)

±1.3%rdg±5dgt (600Ω)

±2.0%rdg±3dgt (6.000kΩ)

Continuity buzzer

600Ω (Buzzer sounds below 90Ω)

Conductor size

φ33mm max.

Applicable standards

IEC 61010-1 CAT IV 300V / CAT III 600V Pollution degree 2

IEC 61010-031, IEC 61010-2-032, IEC 61010-2-033,

IEC 61326-2-2(EMC), IEC 60529 IP40, EN 50581(RoHS)

Power source

R03/LR03 (AAA) (1.5V) × 2

Continuous measuring time

Approx.170 hours (when R03 is used)

(Auto power save : Approx. 10 minutes)

Dimension

204(L) × 81(W) × 36(D)mm

Weight

Approx. 220g (including batteries)
