DAVIS VANTAGE PRO2™

SPECIFITION:

WIRELESS VANTAGE PRO2™

Vantage Pro2™ (6152, 6153) and Vantage Pro2 Plus (6162, 6163) Wireless Weather Stations include two components: the Sensor Suite which houses and manages the external sensor array, and the console which provides the user interface, data

display, and calculations. The Sensor Suite and Vantage Pro2 console communicate via an FCC-certified, license-free, spread- spectrum frequency-hopping (FHSS) transmitter and receiver. User-selectable transmitter ID codes allow up to eight stations to coexist in the same geographic area. The frequency hopping spread spectrum technology provides greater communication

strength over longer distances and areas of weaker reception. The Wireless Vantage Pro2 Plus weather station includes two additional sensors that are optional on the Vantage Pro2: the UV sensor and the solar radiation sensor.

The console may be powered by batteries or by the included AC-power adapter. The wireless Sensor Suite is solar powered with a battery backup. Use WeatherLink Live™ or a WeatherLink® data logger to let your weather station interface with a computer, to log weather data, and to upload weather information to the internet.

The 6152 and 6162 rely on passive shielding to reduce solar-radiation induced temperature errors in the outside temperature sensor readings. The Fan-aspirated 6153 and 6163 combine passive shielding with a solar-powered fan that draws outside air in over the temperature and humidity sensors, providing a much more accurate temperature reading than that available using passive shielding alone.

Sensor Suite

(Includes product numbers: 6152, 6153, 6162, 6163, 6322, 6323, 6327 & 6328)

SPECIFITION:

Operating Temperature          . . -40° to +150°F (-40° to +65°C)

Non-operating Temperature   . . -40° to +158°F (-40° to +70°C)

Current Draw (ISS SIM only) 0.14 mA (average), 30 mA (peak) at 4 to 6 VDC

Solar Power Panel      0.5 Watts (ISS SIM), plus 0.75 Watts (Fan-Aspirated)

Battery (ISS SIM /Fan-Aspirated) . . . . . . . . . . . . . . . . . . . CR-123 3-Volt Lithium cell / 2 - 1.2 Volt NiMH C-cells

Battery Life (3-Volt Lithium cell)         8 months without sunlight - greater than 2 years depending on solar charging

Battery Life (NiMH C-cells, Fan-Aspirated)   Up to 2 years

Fan Aspiration Rate (Fan-Aspirated only)

Intake Flow Rate, full sun       190 feet/min. (0.9 m/s)

Intake Flow Rate, battery only            80 feet/min. (0.4 m/s)

Sensor Chamber Flow Rate, full sun 500 feet/min. (2.5 m/s)

Sensor Chamber Flow Rate, battery only      180 feet/min. (0.9 m/s)

Connectors, Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Modular RJ-11

Cable Type     . . 4-conductor, 26 AWG

Cable Length, Anemometer   40 feet (12 m) (included) 240 feet (73 m) (maximum recommended)
