Specifications of LM520G-LD/LM530G-LD/LM550G-LD Laser Levelers
LM550G-LD UNI-T
LM550G-LD UNI-T
- Stock: In Stock
- Model: Laser Levelers
19,500
Features of LM520G-LD/LM530G-LD/LM550G-LD Laser Levelers
● Highly visible laser
● Self-leveling
● High-capacity Li-ion battery
● Simultaneous charging and power supplying
| Specifications | LM520G-LD | LM530G-LD | LM550G-LD |
| Display type | Green LD | ||
| Laser type | 1V1H | 2V1H | 4V1H |
| Laser points | 3 | 4 | 6 |
| Laser wavelength | 510~515nm | ||
| Light source | ≤1mW | ||
| Laser class | 2 | ||
| Expanded Angle | H130°/V110° | ||
| H/V accuracy | ± 3mm@10m | ||
| Self-leveling range | 3° (±0.5°) | ||
| Self-leveling method | Gravity pendulun magnetic damping | ||
| Self-leveling time | ≤5s | ||
| Working distance | Line 20m, point 25m@300lux | ||
| Operating time | >5h (all lasers on) | ||
| Operating temperature range | -10°C to 40°C | ||
| Storage temperature range | -20°C to 60°C | ||
