Model: HIGH VOLTAGE INSULATION TESTER

Description

Buy Now KEW3127 KYORITSU At Best Price In Pakistan 2025.

High-Voltage Insulation Resistance Tester (Up to 10TΩ)

This advanced insulation resistance tester is designed for high-accuracy insulation diagnostics across a wide voltage range from 250V to 5000V. It delivers powerful performance with a maximum insulation resistance of 10TΩ and short-circuit current up to 5mA, making it ideal for professional electrical and industrial testing applications.

Equipped with diagnostic insulation test modes such as IR, PI, DAR, DD, SV, and RAMP, this instrument ensures comprehensive evaluation of insulation quality. The built-in Bluetooth communication feature allows real-time data transfer and monitoring on PC or Android devices, while memory and logging functions enable easy data management and analysis.

The tester also includes a filter function to reduce noise interference and ensure stable readings. Its rugged IP65-rated design (with lid closed) and rechargeable 12V battery make it reliable and portable for field use.

Key Features

Insulation Resistance up to 10TΩ
Short-Circuit Current: Up to 5mA
Wide Test Voltage Range: 250V to 5000V
Diagnostic Modes: IR, PI, DAR, DD, SV, RAMP
Wireless Connectivity: Bluetooth® 5.0 for real-time data transfer
USB Interface for PC connection
Memory & Logging Functions for easy data storage
Filter Function minimizes electrical noise
Rugged Design: IP65 protection with lid closed
Rechargeable 12V Battery for long operation time

Technical Specifications

Insulation Resistance

Test Voltage	Max Measurement Value	Accuracy
250V	9.99GΩ	±5%rdg ±3dgt
500V	99.9GΩ	±5%rdg ±3dgt
1000V	199GΩ	±5%rdg ±3dgt
2500V	999GΩ	±5%rdg ±3dgt
5000V	9.99TΩ	±20%rdg

Short-Circuit Current: Max 5.0mA
Output Voltage Accuracy: -10% to +20% (depending on range)
Voltage Monitor Accuracy: ±10%rdg ±20V

Voltage & Current Measurement

Voltage Measurement:

AC: 30V to 600V (50/60Hz)
DC: ±30V to ±600V
Accuracy: ±2%rdg ±3dgt

Current Measurement:

Range: 0.00nA to 5.50mA
Accuracy: ±10%rdg

Capacitance Measurement

Range: 5.0nF to 50.0µF (up to 25.0µF at 5000V)
Accuracy: ±5%rdg ±5dgt

General Specifications

Standards: IEC 61010-1, IEC 61010-2-030, CAT IV 600V, IEC 61010-2-034, IEC 61010-031, IEC 61326-1/2-2
Power Source: 12V Rechargeable Lead-Acid Battery (DC 15VA Max)
Communication Interfaces: USB, Bluetooth® 5.0
Protection Rating: IP65 (lid closed)
Operating Temperature: Suitable for field and lab environments

Dimensions & Weight

Instrument Size: 208(L) × 225(W) × 130(D) mm
With Hard Case: 380(L) × 430(W) × 154(D) mm
Instrument Weight: Approx. 4kg (including battery)
Total Weight with Accessories: Approx. 8kg

Ideal For:

Power utilities, electrical maintenance teams, industrial equipment inspections, and insulation testing professionals who require precise, high-voltage measurements.
