KEW3552 KYORITSU Price In Pakistan

Insulation resistance

Test voltage

50V

100V

125V

250V

500V

1000V

Measuring range

(Auto-ranging)

100.0MΩ

200.0MΩ

250.0MΩ

500.0MΩ

20.00GΩ

40.00GΩ

Mid-scale value

2MΩ

5MΩ

5MΩ

10MΩ

100MΩ

200MΩ

First effective measuring range

0.100 to 10.00MΩ

0.100 to 20.00MΩ

0.100 to 25.00MΩ

0.100 to 50.0MΩ

0.100 to 500MΩ

0.100 to 1000MΩ

Accuracy

±2%rdg ±2dgt

Second effective measuring range

0.050 to 0.099MΩ

10.01 to 100.0MΩ

0.050 to 0.099MΩ

20.01 to 200.0MΩ

0.050 to 0.099MΩ

25.01 to 250.0MΩ

0.050 to 0.099MΩ

50.1 to 500MΩ

0.050 to 0.099MΩ

501 to 2000MΩ

0.050 to 0.099MΩ

1001 to 4000MΩ

Accuracy

±5%rdg

(0.050 to 0.099MΩ: ±2%rdg±4dgt)

Rated current

1.0 to 1.1mA

Output short circuit current

1.5mA max

Ω / Continuty

Auto-ranging

40.00/400.0/4000Ω

Accuracy

±2.5%rdg ±8dgt

Output voltage on open circuit

5V（4 to 6.9V）

Output short circuit current

200mA or more

Voltage

Voltage range

AC 2.0 to 600V（45 to 65Hz）

DC -2.0 to -600V +2.0 to +600V

Accuracy

±1%rdg ±4dgt

General

Applicable standards

IEC 61010 CAT Ⅲ 600V / CAT Ⅳ 300V, IEC 61010-2-034

IEC61557-1,2,4 IEC61326-1,2-2 IEC60529（IP40）

Power source

LR6/R6（AA）（1.5V）x4

Communication interface

USB

Dimension / Weight

97(L) x 156(W) x 46(D) mm / Approx. 490g（including battery）

Accessories

7260（Test lead with remote control switch）

7261A（Test lead with alligator clip）

8017A（Extension prod long）

9173（Carrying case）
