KEW6205 KYORITSU Price In Pakistan

• Mains voltage indication

• Display range

• 30 to 270V

• Accuracy

• ±5V

• Protective conductor resistance test

• Measuring range

• 0.00 to 20.00Ω

• Open circuit voltage

• 5V±0.4V DC

• Measuring current

• 200mA DC(nominal value)

• Accuracy

• ±3%rdg±5dgt

• Insulation resistance test

• Rated voltage



• 250V

• 500V

• Measuring range



• 0.00 to 20.00MΩ

• No-load voltage



• 250V DC +20%,-0%

• 500V DC +20%,-0%

• Short circuit current



• 1.5mA DC or less

• Accuracy



• ±2%rdg±3dgt

• Load current/Leakage current test

• Item



• Load current

• Leakage current

• Mains voltage range



• 100 to 253V/50Hz

• Measuring range



• 0.10 to 10.00A rms

• 0.10 to 20.00mA rms

• Accuracy



• ±10%rdg±5dgt

• ±3%rdg±5dgt

• RCD test

• Rated voltage



• 230V -15% to +10%/50Hz

• Rated current



• 10/30mA

• Function



• × 1

• × 5

• Test duration



• 0.0 to 500.0ms

• 0.0 to 40.0ms

• Operating time accuracy



• ±2ms(≦40ms),±8ms(>40ms)

• Power source




• LR6(AA)(1.5V) × 6

• Applicable Standards




• IEC/EN61010-1 CAT II 300V, IEC/EN61010-2-030, IEC 61010-2-034
  IEC/EN61010-031, EN61326-2-2, AS/NZ3760

• Dimension / Weight




• 261(L) × 104(W) × 57(D)mm / Approx. 940g(including batteries)

• Accessories




• (Mains lead),
  (Test lead with Alligator clip),
  (Flat test prod[black]),
  (Adapter for Extension cord),
  (Carrying case),
  (Fuse[10A/250V]),
  (Shoulder strap),
  Buckle, LR6(AA) x 6, Instruction manual

• Optional Accessories




• (USB cable),
  (Printer cable: Mini Din 6pin-D-sub 9pin),
  (Test lead with Alligator clip and Flat test probe)
