UT343A UNI T
- Stock: In Stock
- Model: Coating Thickness Gauge
UT343A Coating Thickness Gauge
UT343A is used to measure the thickness of the plated and
coated sheet on ferrous/non-ferrous, it has the large range up to 1750um, which
is widely used in manufacturing industry, metal-processing industry, chemical
industry, commodity inspection area, and also able to work steadily in workshop
and outdoor.
Specifications | Range |
Certificates | RoHS |
Measuring range | 0~1750um |
Accuracy | ±(3%H+1)um |
Measurement method | Single/Continuous |
Measurement mode | Max/Min/Avg |
Metal type | Ferrous/non-ferrous |
Features | |
Display type | EBTN display |
LCD brightness control | √ |
Rotatable screen | √ |
Unit conversion | √ |
Audio alarm | √ |
LED alarm | √ |
Data storage | 199 groups |
Auto power off | √ |
Low battery indication | √ |
General Characteristics | |
Power | 1.5V battery (LR03) x 2 |
Product color | Red and grey |
Product net weight | About 111g |
Product size | 117mm x 53mm x 37mm |
Standard accessories | Ferrous substrate, non-ferrous substrate |
Standard individual packing | Gift box, English manual |
