SAG-55 FNIRSI

The SAG-55 Intelligent Hot Air Gun is a newly launched portable smart hot air gun designed to meet various application needs. It uses a microcontroller with PID precise temperature control technology, ensuring rapid heating with minimal thermal shock, which extends the lifespan of the heating element. The brushless fan supports adjustable wind speeds from levels 1 to 20, providing low noise, long life, and adaptability to different work environments.

The handle integrates a magnetic sensor that automatically heats up when picked up and cools down into standby mode when returned, making operation simple. The controller and display screen on the handle allow for effortless one-handed adjustment of temperature and wind speed. It also supports three sets of quick temperature/wind speed presets for fast switching.The fast cooling function accelerates cooling, further extending the heating element's lifespan. Real-time monitoring by various sensors ensures the device shuts off heating in case of any abnormalities, ensuring safety. The LCD display and LED indicator clearly show working status and temperature changes.
With its ergonomic handle design for a comfortable grip and compact, portable build, the SAG-55 is the ideal choice for professionals and DIY enthusiasts alike.
Built-in magnetic sensor detects placement angle and triggers sleep mode. Boosted cool air when resting helps cool down faster and protect the heating core.
Low-noise, energy-saving brushless fan with long lifespan. Supports 1-20 levels of linear air volume adjustment for smooth and precise desoldering
Cold air mode with one press for quick cooling. Different colors indicate different temperatures for real-time status monitoring
Easily save 3 temperature and air volume settings (100-450℃) for fast switching. Adapt quickly to different soldering needs with just one press
200-240V AC (EU Plug)
Max Power: 550W
Power Adapter: 118*50*30.6 mm
AC Power Cord: 1.2m
◉ SAG-55 Hot Air Gun x1
◉ 6mm Nozzle x1
◉ Power Adapter x1
◉ Power Cable (Need to select US or EU plug) x1
◉ User Manual × 1
◉ SAG-55 Hot Air Gun x1
◉ 6mm Nozzle x1
◉ Power Adapter x1
◉ Power Cable (Need to select US or EU plug) x1
◉ User Manual × 1

Key Features:

·       Magnetic Sensor Smart Sleep Stand

·       Brushless Fan Smooth Speed Control

·       Hot & Cold Air Switch Faster Cooling Efficiency

·       Three Presets One-Touch Switch

Specifications

Model

SAG-55

Power Supply (Input Voltage)

100-140V AC (US Plug)

Power Parameters

Frequency: 50-60Hz

Temperature Control Range

100℃-450℃ (212℉-842℉)

Display Screen Size

1.54-inch LCD (240*240)

Airflow Rate

80L/min, Adjustable from 1-20 levels

Heating Tube Size

Length 80mm, Diameter 21.6mm (compatible with 850 series nozzles)

Body Dimensions

Handle (excluding nozzle): 260*60*40 mm

Cable Length

Handle Silicone Cable: 1.2m

Operating Noise

<65dB

Overall Weight (including accessories)

≈1391g

Auto off

Never Shutdown, 5 minutes, 10 minutes, 15 minutes

Unit

Celsius (°C) / Fahrenheit (°F)

Language

Simplified Chinese / English

Shortcut

Fan speed 1‒20, Temperature 100‒450°C

Step

5℃ ~ 25℃

Standby

70℃ ~ 100℃

Cooling

Close / Open

Temp CAL

120°C, 220°C, 320°C, 420°C

Brightness

1 ~ 10

Package List:

Set 1 - Standard

◉ Basic Metal Stand x1

Set 2 - Pro

◉ Smart Sleep Stand x1
