MS6208A Mastech Digital Tachometer Contact RPM Meter in Pakistan

The MS6208A Mastech Digital Tachometer is a precision contact-type rotational speed (RPM) measuring instrument designed for accurate measurement of rotational speed in mechanical, industrial, and maintenance applications. It measures rotation speeds from 50 to 19,999 RPM with high accuracy and features useful functions like data logging, MAX/MIN, data hold, and backlit LCD display for easy use in various lighting conditions.

Key Features

• Contact measuring mode for direct RPM measurement
• Measures 50–19,999 RPM with high accuracy ±(0.03%+2)
• Backlit LCD display for clear readings even in low light
• Data logging stores up to 100 measurement groups
• MAX/MIN & data hold functions for detailed analysis
• Auto power off to save battery
• Unit selection: m/min, m/sec, ft/min, ft/sec, in/min
• Low battery indicator alerts when battery is low
• Includes idler wheels, touch tips, and carry bag

Technical Specifications

Measurement

• Range: 50–99.99 RPM / 100–9999.9 RPM / 10000–19999 RPM
• Resolution: 0.01 RPM / 0.1 RPM / 1 RPM
• Accuracy: ±(0.03%+2) across ranges
• Mode: Contact measurement using idler wheels

Display & Performance

• LCD with backlight
• Data logging up to 100 groups
• MAX/MIN/AVG display modes
• Data hold function

Environmental & Power

• Power Supply: 4 × 1.5V AAA batteries
• Operating Temperature: Typically 0–40 °C
• Product Size: ~170 × 60 × 27 mm
• Weight: ~130 g

Applications

• Measuring motor and machine shaft speed
• Industrial maintenance and inspection
• HVAC equipment RPM checks
• Workshop and factory rotational speed diagnostics
• Belt and pulley speed measurement
• Laboratory and research equipment monitoring

Package Includes

• MS6208A Mastech Digital Tachometer
• Measurement idler wheels & touch tips
• Carry bag
• Batteries & User manual
