AR63C Smart Sensor

The AR63C Smart Sensor is a compact digital vibration meter designed to monitor the vibration condition of industrial machinery. It uses a Piezoelectric Ceramic Accelerometer (shear-type) to detect and convert vibration signals into accurate digital readings.

The device measures acceleration, velocity, and displacement of vibration in rotating equipment. It is suitable for preventive maintenance, equipment health monitoring, and quality control in industries such as power generation, petrochemicals, machinery manufacturing, automotive, and metallurgy.

Its lightweight, portable design and key features like auto range switching, backlight, and auto power-off make it an ideal tool for technicians and engineers in field or workshop environments.

Key Features:

• Measures Acceleration, Velocity, and Displacement

• High-precision Piezoelectric Ceramic Accelerometer (shear-type)

• Frequency Range for Acceleration: 10Hz–1KHz (LO), 1KHz–15KHz (HI)

• Frequency Range for Velocity & Displacement: 10Hz–1KHz

• Accuracy: ±5%H ±2 digits

• Signal Output: AC output

• Auto range switching and backlight

• Auto power-off function

• Powered by 2 x AAA batteries

• Lightweight at only 60g

• Delivered in a premium gift box

Technical Specifications:

• Acceleration Range: 0.1 ~ 199.9 m/s²

• Velocity Range: 0.1 ~ 199.9 mm/s

• Displacement Range: 0.001 ~ 1.999 mm

• Power: 2 x AAA batteries

• Product Size: 150 x 40 x 20 mm

• Net Weight: 60g

• Packaging: Gift box

• Carton Quantity: 40 units

• Carton Size: 52 x 40 x 49 cm

• Gross Weight per Carton: 15 kg
