Fluke 810 Vibration Tester – Best Price in Pakistan (2025)

The Fluke 810 Vibration Tester is one of the most advanced vibration diagnostic tools available for industrial maintenance teams in Pakistan. It is designed for fast, reliable fault detection—helping you reduce unplanned downtime, plan repairs, and keep equipment running at peak performance.

With its built-in diagnostic engine, the Fluke 810 gives clear, step-by-step fault identification without needing previous measurement history. It delivers actionable insights, severity levels, and repair recommendations—putting vibration analysis expertise directly in your hands.

What the Fluke 810 Helps You Do

• Quickly troubleshoot problem equipment.

• Identify root causes of mechanical failures.

• Verify repairs before and after maintenance.

• Commission new machines and ensure proper installation.

• Predict faults early and reduce downtime.

• Improve planning, spare-parts management, and team productivity.

• Train new technicians with easy-to-follow diagnostics.

Common Faults Detected

• Unbalance

• Misalignment

• Looseness

• Bearing failure

Suitable for motors, fans, pumps, compressors, gearboxes, belt/chain drives, spindles, and more.

Technical Specifications – Fluke 810 Vibration Tester

Diagnostic Performance

• Motor speed range: 200–12,000 rpm

• Output: Plain-text diagnosis, fault severity (slight/moderate/serious/extreme), repair advice

• Displays cited peaks & spectra for detailed analysis

Electrical & Signal Processing

• Automatic ranging

• 4-channel, 24-bit A/D converter

• Bandwidth: 2 Hz – 20 kHz

• Sampling rate: 2.5 kHz – 50 kHz

• DSP functions: anti-alias filter, FFT, averaging, windowing

• Dynamic range: 128 dB

• SNR: 100 dB

• FFT resolution: 800 lines

• Frequency units: Hz, orders, cpm

• Amplitude units: in/sec, mm/sec, VdB (US/EU)

• Storage: 2 GB internal + SD card slot

General Specifications

• Size: 18.56 × 7.00 × 26.72 cm

• Weight: 1.9 kg

• Display: 5.7" color TFT LCD

• Connections:

  • Triaxial sensor (M12)

  • Single-axis (BNC)

  • Tachometer (Mini-DIN)

  • USB 2.0

• Battery: 14.8 V Li-Ion, 8-hour run time, 3-hour charge

• AC adapter: 100–240 V, 50/60 Hz

• Warranty: 3 years

Environmental

• Operating temp: 0°C to 50°C

• Storage: -20°C to 60°C

• Humidity: 10–95% (non-condensing)

• Approvals: CE, CSA, WEEE, China RoHS

• EMC: EN 61326-1, EN 61010-1

Sensor Specifications

• Type: Accelerometer

• Sensitivity: 100 mV/g ±5%

• Range: 80 g peak

• Frequency response:

  • Z-axis: 2–7,000 Hz

  • X/Y-axis: 2–5,000 Hz

• Non-linearity: 1%

• Power: 18–30 VDC, 2–10 mA

• Shock limit: 5000 g peak

• Housing: 316L stainless steel

• Mounting: magnetic base or screw mount

• Connector: 4-pin M12

• TEDS compatible

• Warranty: 1 year

Tachometer Specifications

• Range: 6–99,999 rpm

• Accuracy:

  • 6–5999.9 rpm: ±0.01% +1 digit

  • 6000–99999 rpm: ±0.05% +1 digit

• Resolution: 0.1 rpm

• Effective distance: 1–100 cm

• Laser Class: Class 2

• Powered by Fluke 810

• Weight: 96 g

• Warranty: 1 year
