FLUKE 88V

Technical Specifications

DCV

Maximum voltage

1000 V

Accuracy

±(0.1% + 1)

Best resolution

0.01 mV

ACV

Maximum voltage

1000 V

Accuracy

±(0.5% + 2)

AC bandwidth

5 kHz

Best resolution

0.01 mV

DC current

Maximum amps

10 A

Amps accuracy

±(0.4 % + 2)

Best resolution

0.001 mA

AC current

Maximum amps

10 A

Amps accuracy

±(1.2% + 2)

Best resolution

0.001 mA

Resistance

Maximum resistance

50 MΩ

Accuracy

±(0.4% + 1)

Best resolution

0.1 Ω

Capacitance

Maximum capacitance

9,999 µF

Accuracy

±(1% + 2)

Best resolution

0.01 nF

Frequency

Maximum frequency

200 KHz

Accuracy

±(0.005% + 1)

Best resolution

0.01 Hz

Duty cycle

Maximum duty cycle

99.9%

Accuracy

within 2% per KHz + 0.1%

Best resolution

0.1%

Temperature measurement

-200.0°C – 1090°C
-328.0°F – 1994.0°F, 1.0% excluding probe

80 BK temperature probe

-40 °C – 260°C
-40 °F – 500°F, 2.2°C or 2% whichever is greater

Conductance

Maximum conductance

60.00 nS

Accuracy

±(1.0% + 10)

Maximum resolution

0.01 nS

Operating range

Operating temperature

-20°C – 55°C

Storage temperature

-40°C – 60°C

Physical

5.2 x 9.8x 20.1 cm (2.06 x 3.86 x 7.93 in)
624 g (22 oz.)
