Fluke 568 Ex Price In Pakistan

Buy Now Fluke 568 Ex Intrinsically Safe Infrared Thermometer

At Best Price In Pakistan 2025

The Fluke 568 Ex Intrinsically Safe Infrared Thermometer is engineered for hazardous and explosive environments where safety, accuracy, and certification are critical. Approved by major global rating bodies, the 568 Ex is safe for use in Class I Div. 1 & 2 and Zone 1 & 2 locations, making it ideal for industries such as oil & gas, chemicals, petrochemicals, manufacturing, and pharmaceuticals.

With its intuitive three-button interface, advanced menu system, and rugged design, the Fluke 568 Ex lets technicians perform precise non-contact and contact temperature measurements with ease — even in the most demanding conditions. The 50:1 distance-to-spot ratio ensures highly accurate readings on small targets from a safe distance.

The device includes K-type thermocouple support, giving you the flexibility to choose between IR and contact temperature measurements. Combined with adjustable emissivity, high accuracy, and built-in materials table, the 568 Ex delivers an all-in-one temperature testing solution for Ex-rated environments.

Key Features

✔️ Certified Intrinsically Safe (Class I Div. 1 & 2, Zone 1 & 2)
✔️ 50:1 Distance-to-Spot Ratio — measure small targets from farther away
✔️ High Accuracy (±1%) for both non-contact and contact measurements
✔️ Adjustable emissivity with built-in material table
✔️ Compatible with K-type thermocouples
✔️ Instant alarms — audible + visual for out-of-range temperatures
✔️ Rugged, ergonomic, industrial-grade body
✔️ Quick-access soft keys and graphical menu interface
✔️ Record up to 99 data points and transfer via USB
✔️ Two-level backlight for easy viewing in dark or bright conditions
✔️ Comes with K-type bead probe
✔️ Powered by two AA batteries
✔️ Two-year warranty

Technical Specifications: Fluke 568 Ex Intrinsically Safe Infrared Thermometer

Infrared Measurement

• Range: –40°C to 800°C (–40°F to 1472°F)

• Accuracy:

  • Below 0°C: ±(1°C + 0.1°/°C)

  • Above 0°C: ±1% or ±1°C (whichever is greater)

• Display Resolution: 0.1°C / 0.1°F

• Spectral Response: 8–14 µm

• Response Time: < 500 ms

• Distance-to-Spot Ratio (D:S): 50:1

• Laser: Single-point

• Minimum Spot Size: 19 mm




Thermocouple (K-type) Input

• Range: –270°C to 1372°C (–454°F to 2501°F)

• Accuracy:

  • < –40°C: ±(1°C + 0.2°/°C)

  • ≥ –40°C: ±1% or 1°C




Data & Settings

• Emissivity: Adjustable (0.10–1.00), or choose from built-in materials table

• Data storage: 99 readings

• Min/Max/Avg/Dif: Yes

• High/Low Alarms: Audible + visual

• Display: Dot-matrix with menu system

• Backlight: Two levels (normal & extra bright)

• Trigger Lock: Yes

• Units: °C/°F selectable




Power

• Battery Type: 2 × AA / LR03 (type-approved)

• Battery Life:

  • 4 hours (laser + backlight ON)

  • 100 hours (laser + backlight OFF)




Environmental

• Operating Temperature: 0°C to 50°C

• Storage Temperature: –20°C to 60°C




Included K-Type Bead Probe

• Range: –40°C to 260°C

• Accuracy: ±1.1°C

Ideal For Use In

• Oil & Gas Plants

• Petrochemical Facilities

• Chemical Processing

• Pharmaceutical Production

• Hazardous / Explosive Environments

• Maintenance & Safety Inspections
