Logic Probe
Model: 24MHz 8CH USB Cable set
USB Logic Analyzer Device Set USB Cable 24MHz 8CH 8-Channel 24MHz MCU ARM GA M100Overview:Sampling rate up to: 24 MHz , can be 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz;The logic for each channel sampling rate of 24M/s. General applications around 10M,..
2,100
Out Of Stock
Model: Logic Probe
The LP-2800 is a high
quality logic probe for use with TTL, DTL and CMOS ICs.
The probe has a memory function which can detect the occurrence of single
pulses or logic level. One shot and low repeat rate narrow pulses, which are
nearly impossible to see even with a fast scope, are easily detecta..
7,000
Model: Logic Probe
Logic Probe which functions to help determine High or Low logic output.Specifications :- Input impedance : 1M Ohm- Pulse width : 30ns (min)- Input frequency : 17Mhz (max)- Capable of measuring High or Low logic from CMOS or TTL voltage level- Equipped with overvoltage protection..
9,500
Model: Logic Pulser
Logic Pulser from K&HSpecifications:- Power supply = 3 - 5V DC- Input impedance = 1MOhm- Repeat pulse = 0.5pps / 400pps- Output pulse width = 10us- Output protection = + 35V/15 sec- Power supply protection = 25V/25 sec- Dimensions = 212 x 26.5 x 18 mm- Power supply protection..
Model: LP 1 Logic Probe
Description :A high-quality logic probe for use with TTL, DTL, and CMOS integrated circuits. The probe contains a memory function that can detect the occurrence of single pulses or logic levels. A single shot and low repetition rate of pulses that are almost impossible to see even with a r..
3,000
Model: Tp2 Logic Pulser
General DescriptionThe Logic Pulser is an effective tool for the inspection and
repair of logic circuity. It can be used to directely inject a signal into logic
circuits without removing the IC or breaking the circuit. Using the logic probe
as a monitor you can know not only if there is wiring er..
4,000
Showing 1 to 6 of 6 (1 Pages)
