FLUKE 283 FC/PV Price In Pakistan

Buy Now Fluke 283 FC/PV Solar Digital Multimeter & Wireless Current Clamp At Best Price in Pakistan 2025

The Fluke 283 FC/PV Solar Digital Multimeter and a283 FC Wireless Current Clamp deliver unmatched safety, precision, and performance for solar PV professionals working in high-voltage DC environments up to 1500 V. Whether you are maintaining utility-scale solar arrays, troubleshooting inverters, inspecting combiner boxes, or servicing wind, rail, and data-center power systems, the Fluke 283 FC/PV offers the highest protection level and industry-leading accuracy to keep your work fast, safe, and reliable.

Engineered for next-generation solar installations, this advanced multimeter package is rated CAT III 1500 V / CAT IV 1000 V, making it one of the safest frontline diagnostic tools available in Pakistan.

Unmatched Safety & Convenience for Solar Professionals

The Fluke 283 FC Multimeter is designed specifically for modern solar PV systems operating at high voltages. It includes a complete set of CAT III 1500 V safety-rated accessories so you can measure without compromise.

Staubli MC4 test leads ensure secure, fast PV string connections up to 1500 V DC, while TL175-HV silicone test leads provide flexibility and safety across inverter, string, module, and combiner box testing.

A bright backlit LCD screen, illuminated keypad, magnetic hanging strap, and rugged protective hard case make this multimeter trustworthy on any job site—from hot rooftops to remote solar farms.

Key Features & Benefits

✔ Highly Accurate Voltage Measurements

Designed for precise solar troubleshooting, even on large utility-scale systems. Reliable accuracy across DC and AC voltage ranges up to 1500 V.

✔ Wireless Current Measurement up to 60 A AC/DC

Using the included a283 FC wireless clamp, you can measure individual module strings safely and with full True-RMS accuracy.

✔ Visual & Audio Polarity Indicators

Prevents dangerous wiring mistakes and ensures correct module connections.

✔ User-Defined Limit Gauge

Set custom measurement thresholds to instantly get go/no-go visual and audio alerts—ideal for repetitive PV string measurements.

✔ Readiness Self-Check

Unique built-in diagnostic system checks meter calibration, battery, test lead condition, and AC/DC voltage measurement readiness before testing—no more second-guessing.

✔ Save, Log & Transfer Data

Log measurements with time/date stamps and transfer wirelessly via Fluke Connect™ for analysis, trending, and reporting.

✔ Full CAT III 1500 V / CAT IV 1000 V Safety Compliance

Engineered for direct work on solar arrays, inverters, and high-voltage DC systems that are increasingly common in Pakistan’s solar installations.

Why Safety Matters: CAT III 1500 V for Modern Solar Installations

Utility-scale solar plants now use 1500 V DC systems, allowing:

• Longer PV strings
• Fewer inverters
• Higher efficiency
• Lower BOS cost

With higher voltages becoming common, using properly rated meters is critical.

The Fluke 283 FC/PV meets IEC 61010-2-032 requirements for high-voltage PV installations and is fully compatible with:

• CAT III 1500 V MC4 PV connectors
• CAT IV inverter AC outputs (800+ V)
• High-power DC strings and combiner boxes

This makes it a complete frontline troubleshooting kit for solar engineers and EPC technicians.

User-Defined Limit Gauge

A powerful tool for repetitive string testing.
Set expected values based on system design, and the meter will alert you to deviations instantly.

Perfect for:

• Commissioning PV farms
• O&M inspections
• Warranty testing
• Detecting underperforming strings

Switch between saved profiles or set new limits using the dedicated Limit Gauge button.

Multimeter Readiness Self-Check

Before testing, the meter automatically checks:

• Calibration status
• Battery level
• Test leads condition
• AC/DC voltage detection functionality

This ensures maximum confidence—especially important at remote solar farms where revisits are costly.

Wireless a283 FC True-RMS Current Clamp

The included a283 FC wireless clamp adds tremendous flexibility:

• Measures 60 A AC/DC
• CAT III 1500 V / CAT IV 1000 V rated
• Wireless transmission for closed-cabinet testing
• Thin jaw for combiner boxes
• Non-contact design enhances safety
• 80+ hour battery life

Ideal for string monitoring, system balancing, and performance diagnostics.

Measure Voltage & Current Simultaneously

The 283 FC + a283 FC clamp allow:

• Synchronous voltage + current measurement
• Automatic VA (power) calculation
• Time-stamped data for accurate comparison
• Multi-parameter viewing (e.g., voltage + current + frequency)

Great for inverter testing, performance checks, and module diagnostics.

Logging, Saving & Fluke Connect™

• Real-time clock for timestamped logging
• Adjustable logging intervals
• Internal memory for measurement storage
• Wireless transfer to Fluke Connect™
• Cloud storage + report creation
• Live trending and remote collaboration

Perfect for field reports, audits, commissioning, and long-term O&M records.

What’s Included

✓ Fluke 283 FC Digital Multimeter
✓ Fluke a283 FC Wireless True-RMS Current Clamp
✓ TL175-HV Premium Silicone Test Leads
✓ Staubli MC4 PV Test Leads
✓ Magnetic hanging strap
✓ Hard carrying case
✓ Batteries and documentation

Specifications

Fluke 283 FC Digital Multimeter

Environmental & Mechanical

• Operating temp: −10 °C to 60 °C
• Storage temp: −30 °C to 70 °C
• Humidity: Up to 90%
• Drop test: 2 meters
• Ingress protection: IP52
• Overvoltage: CAT III 1500 V / CAT IV 1000 V
• Size: 22.5 × 10.5 × 5.7 cm
• Weight: 0.7 kg
• Battery life: 150 hours (typical)

Fluke a283 FC Wireless Current Clamp

General
