ES3001P FUZRR
- Stock: Pre-Order
- Model: Ground Resistance & Soil Resistivity Tester
FUZRR ES3001P Ground Resistance & Soil Resistivity Tester in Pakistan
The FUZRR ES3001P Ground Resistance & Soil Resistivity Tester is a professional multifunctional electrical testing instrument designed for accurate measurement of earth resistance, grounding resistance, soil resistivity, ground voltage, and DC voltage. It supports multiple testing methods, including precision four-wire, three-wire, and two-wire measurement, making it suitable for professional electrical, power, telecommunications, industrial, and grounding system inspections.
With a microprocessor-controlled measurement system, large HD segment LCD display, fast filtering technology, 500 groups of data storage, USB connectivity, and Bluetooth APP support, the FUZRR ES3001P provides a practical solution for both field testing and professional measurement documentation.
If you are looking for a reliable soil resistivity tester in Pakistan, earth resistance tester in Pakistan, or professional ground resistance tester, the FUZRR ES3001P offers multiple measurement functions in one instrument.
FUZRR ES3001P Ground Resistance Tester – Key Features
- Multifunctional earth and ground resistance tester
- Soil resistivity measurement: 0.00Ωm to 9999kΩm
- Grounding resistance measurement: 0.00Ω to 200.0kΩ
- AC voltage measurement: 0.000V to 750.0V
- DC voltage measurement: 0.000V to 999.9V
- Precision four-wire, three-wire, and simple two-wire measurement methods
- Double-clamp method for grounding resistance measurement
- Fast filtering technology for reducing electrical interference
- Auxiliary grounding resistance measurement function
- 500 groups of internal data storage
- Bluetooth APP for remote control and real-time monitoring
- USB interface for data reading and record saving
- Historical data reading and report analysis support
- Large HD segment-code LCD display
- Built-in rechargeable 11.1V lithium battery
- Adjustable automatic power-off function
- IP45 protection
- Designed according to relevant electrical testing and safety standards
What Is the FUZRR ES3001P Soil Resistivity Tester?
The FUZRR ES3001P is an advanced multifunctional earth resistance and soil resistivity tester used to evaluate grounding systems and the electrical characteristics of soil. Soil resistivity measurement is particularly important when designing, installing, testing, or maintaining grounding and earthing systems.
The tester uses microprocessor-controlled technology to perform accurate measurements using different test configurations. Its support for four-wire soil resistivity measurement makes it suitable for professional grounding engineering applications where reliable soil data is required.
FUZRR ES3001P Measurement Functions
Ground Resistance Measurement
The ES3001P can measure grounding resistance from 0.00Ω to 200.0kΩ. It supports several measurement methods, including two-wire, three-wire, four-wire, and double-clamp techniques, depending on the application and test configuration.
Soil Resistivity Measurement
One of the key advantages of the FUZRR ES3001P over basic earth resistance testers is its dedicated soil resistivity measurement capability. The measurement range is 0.00Ωm to 9999kΩm, with an electrode spacing range of 0.1m to 100.0m.
Soil resistivity testing can be useful for grounding system design, earthing installation assessment, electrical infrastructure projects, and evaluating soil conditions before installing grounding electrodes.
Ground Voltage Measurement
The FUZRR ES3001P measures voltage to ground from 0.000V to 750.0V. This function can assist technicians in evaluating electrical conditions around grounding systems.
DC Voltage Measurement
The tester also provides DC voltage measurement from 0.000V to 999.9V, giving users an additional electrical measurement function in a single portable instrument.
Four-Wire Soil Resistivity Testing
The four-wire measurement method is an important feature of the FUZRR ES3001P for professional soil resistivity testing. Using multiple electrodes and a suitable test configuration, technicians can evaluate soil resistivity for grounding system planning and engineering applications.
The ES3001P supports electrode spacing from 0.1m to 100.0m, providing flexibility for different field-testing requirements.
Advanced Data Storage & Connectivity
The FUZRR ES3001P Earth Resistance Tester can store up to 500 groups of measurement data. This allows technicians to retain test results and review measurements without manually recording every reading.
Bluetooth APP Connectivity
The built-in Bluetooth APP functionality supports remote control, real-time monitoring, and data reading. Users can access measurement information through a compatible mobile application for convenient field operation.
USB Data Transfer
The ES3001P includes a USB interface for reading stored records and transferring measurement data. This can be useful when creating records, reviewing historical measurements, or preparing technical reports.
Fast Filtering Technology for Stable Measurements
Electrical environments can contain interference that may affect grounding measurements. The FUZRR ES3001P uses fast filtering technology designed to reduce interference and support more stable measurement results.
The instrument can also display the resistance value of the auxiliary electrode, helping technicians identify potential measurement errors caused by environmental or electrode conditions.
FUZRR ES3001P Technical Specifications
| Specification | FUZRR ES3001P |
|---|---|
| Product Type | Multifunction Ground Resistance & Soil Resistivity Tester |
| Grounding Resistance | 0.00Ω ~ 200.0kΩ |
| Grounding Resistance Resolution | 0.01Ω ~ 100Ω |
| Soil Resistivity | 0.00Ωm ~ 9999kΩm |
| AC Voltage | 0.000V ~ 750.0V |
| DC Voltage | 0.000V ~ 999.9V |
| Measurement Methods | Precision four-wire, three-wire, simple two-wire, selection and double-clamp methods |
| Test Waveform | Sine wave |
| Test Frequency | 128Hz |
| Data Storage | 500 groups |
| Electrode Spacing | 0.1m ~ 100.0m |
| Power Supply | Built-in 11.1V lithium battery |
| USB Interface | Yes |
| Bluetooth APP | Yes |
| Backlight | Yes |
| Automatic Shut-Off | 15 minutes by default; customizable |
| Grounding Auxiliary Test | 0.00kΩ ~ 200.0kΩ |
| Operating Condition | 23°C ± 5°C, below 75% RH |
| Instrument Weight | Approx. 1880g including battery |
| Test Cable Weight | Approx. 1300g including simple test cables |
| Ingress Protection | IP45 |
Applications of FUZRR ES3001P Ground Resistance & Soil Resistivity Tester
The FUZRR ES3001P is suitable for a wide range of professional grounding, electrical inspection, and soil resistivity applications.
- Electrical grounding and earthing system testing
- Soil resistivity surveys
- Grounding system design and assessment
- Power distribution systems
- Electrical substations and infrastructure
- Telecommunication installations
- Transmission towers and power lines
- Lightning protection grounding systems
- Factory grounding grids
- Petroleum and oil field installations
- Gas stations
- Computer rooms and data center grounding systems
- Meteorological installations
- Industrial electrical maintenance
- Electrical engineering and technical inspection
Why Choose FUZRR ES3001P Earth Resistance Tester?
The FUZRR ES3001P is designed for professionals who require more than a basic earth resistance meter. Its combination of ground resistance, soil resistivity, AC voltage, and DC voltage measurements makes it a versatile instrument for electrical and grounding applications.
- Multifunction Testing: Measure ground resistance, soil resistivity, AC voltage, and DC voltage with one instrument.
- Multiple Grounding Methods: Supports two-wire, three-wire, four-wire, and double-clamp measurement techniques.
- Wide Soil Resistivity Range: Measures soil resistivity from 0.00Ωm to 9999kΩm.
- Large Data Memory: Stores up to 500 groups of measurement results.
- Bluetooth & USB: Transfer, monitor, and review measurement data conveniently.
- Professional Field Design: Rechargeable battery, LCD backlight, IP45 protection, and portable construction support field work.
- Interference Reduction: Fast filtering technology helps reduce the effect of electrical interference during measurements.
FUZRR ES3001P vs ES3000P
The FUZRR ES3001P is the more advanced model when soil resistivity and four-wire testing are required. While the ES3000P focuses on two-wire and three-wire grounding resistance measurement with AC/DC voltage testing, the ES3001P adds four-wire grounding measurement, soil resistivity measurement, wider grounding resistance range, and additional measurement flexibility.
| Feature | ES3000P | ES3001P |
|---|---|---|
| Two-Wire Ground Resistance | Yes | Yes |
| Three-Wire Ground Resistance | Yes | Yes |
| Four-Wire Ground Resistance | No | Yes |
| Soil Resistivity | No | Yes |
| AC Voltage | Yes | Yes |
| DC Voltage | Yes | Yes |
| Ground Resistance Range | 0.00Ω ~ 20.00kΩ | 0.00Ω ~ 200.0kΩ |
| Data Storage | 500 groups | 500 groups |
| Bluetooth APP | Not specified | Yes |
| USB Interface | Yes | Yes |
FUZRR ES3001P Soil Resistivity Tester in Pakistan
If you are looking for a professional soil resistivity tester in Pakistan for grounding system design, electrical engineering, power infrastructure, or industrial applications, the FUZRR ES3001P is a versatile option with multiple testing methods and data management capabilities.
Its combination of soil resistivity measurement, four-wire testing, grounding resistance measurement, AC/DC voltage testing, Bluetooth connectivity, USB data transfer, and 500-group memory makes it suitable for professional field measurements.
Buy FUZRR ES3001P Ground Resistance Tester in Pakistan
Looking to buy FUZRR ES3001P Ground Resistance & Soil Resistivity Tester in Pakistan? Test Instruments Pakistan provides professional testing and measurement instruments for electrical engineers, technicians, contractors, industries, laboratories, and technical professionals.
Contact Test Instruments Pakistan for the latest FUZRR ES3001P price in Pakistan, availability, quotation, and delivery information.
Frequently Asked Questions About FUZRR ES3001P
What is the FUZRR ES3001P used for?
The FUZRR ES3001P is used for measuring grounding resistance, earth resistance, soil resistivity, AC voltage, and DC voltage. It is designed for professional grounding and electrical testing applications.
What is the soil resistivity range of ES3001P?
The FUZRR ES3001P measures soil resistivity from 0.00Ωm to 9999kΩm.
Does the ES3001P support four-wire testing?
Yes. The ES3001P supports precision four-wire measurement in addition to three-wire and simple two-wire measurement methods.
What is the grounding resistance range of FUZRR ES3001P?
The grounding resistance measurement range is 0.00Ω to 200.0kΩ.
How much data can the ES3001P store?
The FUZRR ES3001P can store up to 500 groups of measurement data.
Does FUZRR ES3001P support Bluetooth?
Yes. The instrument supports a Bluetooth APP for remote control, real-time monitoring, and reading measurement data.
Does FUZRR ES3001P have USB connectivity?
Yes. The built-in USB interface can be used for reading stored data, saving records, and transferring measurement information.
What is the electrode spacing range?
The supported electrode spacing range is 0.1m to 100.0m, allowing the instrument to be used for different soil resistivity field-testing requirements.
Where can FUZRR ES3001P be used?
The ES3001P can be used in telecommunications, power systems, meteorological installations, computer rooms, oil fields, power distribution lines, transmission towers, gas stations, factory grounding grids, lightning protection systems, and other electrical grounding applications.
Order FUZRR ES3001P Soil Resistivity Tester from Test Instruments Pakistan
For professional earth resistance, ground resistance, and soil resistivity testing, the FUZRR ES3001P provides multiple measurement methods and advanced data management features in one portable instrument.
Contact Test Instruments Pakistan today to check the latest price, stock availability, delivery options, and quotation for the FUZRR ES3001P Ground Resistance & Soil Resistivity Tester in Pakistan.
